Rear Axle for Tao Tao 4FUN Go-Kart

These axles are model specific.  DO NOT ORDER if your make and model are not listed.  There is a 50% restock fee plus shipping for returned axles.

*Axles are standard shipping only - We can only ship axles to the 48 Contiguous States

This axle is known to fit the Tao Tao 4FUN 150 and 200 go-karts.  Please use the measurements and pictures to help insure the correct fit.

Axle description:

• Overall length: 113.6cm (44.75 in)

• 20mm*1.5 threaded ends
• 23 splines on each end
• Diameter of splines at both ends: 23.78mm (0.936 in)

• Diameter in center of axle 33.03mm (1.30 in)

• Flange closest to an end of the axle has (4) 8mm*1.25 threaded holes
• Flange closest to the middle of the axle has (6) 8.8mm holes
• Distance between flanges is approximately 12.56 inches

• Distance from end of axle to flange closest to the end is approximately 12.0 inches

• Distance from end of axle to flange in the middle is approximately 19.43 inches

• Ends of axle are drilled for cotter keys
