Stator Magneto Flywheel - 50cc 70cc 90cc 100cc 110cc 125cc Horizontal Engine - Version 3
Stator Magneto Flywheel
Version 3
Stator magneto flywheel for 50cc thru 125cc engines. May also fit other engines. Please use the measurements and pictures to match your part.
Flywheel description:
- Outside height of brass: 34.4mm (1.35 in)
- Overall height: 42mm (1.66 in)
- Overall OD including tab: 112.2mm (4.4 in)
- Overall OD not including tab: 109mm (4.32 in)
- ID of magnetic area: 85mm (3.3 in)
- OD of inside hole: 28mm (1.09 in)
- ID of inside hole: 18mm (0.73 in) flat side
- Cutout flywheel key notch.
- OD of starter clutch: 80mm (3.14 in)
Stator Magneto Flywheel
Version 3
Stator magneto flywheel for 50cc thru 125cc engines. May also fit other engines. Please use the measurements and pictures to match your part.
Flywheel description:
- Outside height of brass: 34.4mm (1.35 in)
- Overall height: 42mm (1.66 in)
- Overall OD including tab: 112.2mm (4.4 in)
- Overall OD not including tab: 109mm (4.32 in)
- ID of magnetic area: 85mm (3.3 in)
- OD of inside hole: 28mm (1.09 in)
- ID of inside hole: 18mm (0.73 in) flat side
- Cutout flywheel key notch.
- OD of starter clutch: 80mm (3.14 in)
$13.47
Original: $38.50
-65%Stator Magneto Flywheel - 50cc 70cc 90cc 100cc 110cc 125cc Horizontal Engine - Version 3—
$38.50
$13.47Description
Stator Magneto Flywheel
Version 3
Stator magneto flywheel for 50cc thru 125cc engines. May also fit other engines. Please use the measurements and pictures to match your part.
Flywheel description:
- Outside height of brass: 34.4mm (1.35 in)
- Overall height: 42mm (1.66 in)
- Overall OD including tab: 112.2mm (4.4 in)
- Overall OD not including tab: 109mm (4.32 in)
- ID of magnetic area: 85mm (3.3 in)
- OD of inside hole: 28mm (1.09 in)
- ID of inside hole: 18mm (0.73 in) flat side
- Cutout flywheel key notch.
- OD of starter clutch: 80mm (3.14 in)
